Technical characteristics
● Ceramic cartridge Ø35 mm.
● Diverter 2 ways without closure.
● Flow rate at 3 bar: 20 l/min through bath outlet and 12 l/min through
shower outlet.
● Thermal shock resistent and anti-Legionella chemical.
● Use pressure between 1-5 bar. Recomended pressure 3 bar.
● Resists static pressure equal to or less than 10 bar and water
hammer up to 25 bar.
● 3 bar acoustic level less than 20 dB.
● Comfort benefits of fidelity, sensibility and constancy in temperature
selection.
● Recomended temperature for hot water: 55ºC. Maximum
temperature of use: 65ºC up to 1 hour at 90ºC.
Tests
● Water tightness, flow rate, mechanical behavior under pressure,
mechanical resistance, dimensional, acoustical and corrosion test
according to european standards EN 817 and EN 248.
