Technical characteristics
● Certification AENOR.
● Ceramic cartridge Ø40 mm.
● Water saving system S2 through the handle opening in two fases and Cold opening central system S3.
● Flow rate at 3 bar: 12 l/min.
● Thermal shock resistent and anti-Legionella chemical.
● Guarantee of 5 year for tapware and 3 years for accesories.
● Use pressure between 1-5 bar. Recomended pressure 3 bar.
● Resists static pressure equal to or less than 10 bar and water
hammer up to 25 bar.
● 3 bar acoustic level less than 20 dB.
● Comfort benefits of fidelity, sensibility and constancy in temperature
selection.
●Recomended temperature for hot water: 55oC. Maximum
temperature of use: 65oC up to 1 hour at 90oC.
● Chromed surface: 15 microns thick of nickel and 0.3 microns thick of
chrome.
● Termostop Black system for maximum water temperature limitation.
Tests
● Water tightness, flow rate, mechanical behavior under pressure, mechanical resistance, dimensional, acoustical and corrosion test according to European standards EN 817 and EN 248.
